IMAC 40% laser 200

[guy89zx7]

I bought a set of plans from Devin York for the 40% laser but half of the elevator is blacked out. Also the vertical stab and rudder is not real clear, does anyone have a copy of these plans that show these clear? If so could I get those areas copied? I will pay for them.
Thanks
Guy



[TonyHallo]

The plans were drawn by Jack Strickland, this may help others identify the plans. My plans look the same however there is sufficient detail to build the elevator. Only the upper portion is dark.



[Bartman]

can you guys take a pics of the area of the plans you're talking about?



[guy89zx7]

They are Jack Strickland's. I was just hoping someone had a better copy of the areas.



[TonyHallo]

I got my cowl from Devin, nice glass work, not sure when I will build this plane. I had a 33% designed by Wayne Urley that was very similar in construction this one is just a little bigger. The 33% plans showed a geared .60 glow motor for power. Today we use 100 cc!



[Forgues-Research]

I bought a set of plans from Devin York for the 40% laser but half of the elevator is blacked out. Also the vertical stab and rudder is not real clear, does anyone have a copy of these plans that show these clear? If so could I get those areas copied? I will pay for them.
Thanks
Guy

I have a set of Jack Strickland (RIP) plans of the 40% laser , let me check if I can find what your looking for



[guy89zx7]

Thanks Roger.



[Forgues-Research]

Thanks Roger.

I have the drawing, but when I went to have it scanned for you, they were asking $10, I'm willing to do it if you are willing to pay for it



[guy89zx7]

I have no problem doing that Roger. Does that include the vertical stab and rudder?



[Forgues-Research]

I have no problem doing that Roger. Does that include the vertical stab and rudder?

I will have both sheets scanned, since the fin/rudder is on one sheet and the stab/elevator is on the other,
I will go back but this time will see my usual guy, he normally gives me a good price, will let you know
