bigblueswope
100cc
I'm done with slime. [emoji12]. And I won't be building it for quite a while.
BJ Swope
BJ Swope
3D Cbarnes 3D Slab Thread
- Thread starter BalsaDust
- Start date
bigblueswope
100cc
I've got some 6S 3300 mah Glaciers I fly in my 60" EF Edge. But I'll buy what is best for this size if I need to.
BJ Swope
BJ Swope
BalsaDust
Moderator
OK so here we go.
6S setup
motor
http://www.hobbyking.com/hobbyking/...SK3_4250_500kv_Brushless_Outrunner_Motor.html
ESC
This esc will work for the 4S or 6S setup. Its a little pricey buts its nice because you can crank the voltage up to the BEC. Most only put 5 volts out and its nice to get it up to 6V for the servos but can go up to 8.4volt if your servos can take it.
http://www.hobbyking.com/hobbyking/...Platinum_100A_V3_Brushless_ESC_w_10A_BEC.html
Battery
The 6S pack you have will work but its a bit large and all that weight hanging off one side will make it KE different in both directions. I would drop back to either a pair of 3S 3300's in series or save some weight and drop back to like a pair of 2800-3000 mah 3S packs.
Prop Start with like a 13x6 and work from their but prop it to pull around 60/65 amps.
4S setup
Motor
http://www.valuehobby.com/power-systems/brushless-motors/outrunner-airplane/gforce-g32-800kv.html
Use the same ESC as listed above.
Battery
Use a 4S 3700-4000mah pack.
Prop
Start with like a 14x7 but you will want to prop it to pull around 80/90 amps. I know the specs on the motor only say 12x6 on 4S and max load of 50amps. Those are CJ numbers. If you plan to stay WOT the whole time it will cook the motor and we will need to figure out something else but if your like me and most the time the throttle will be 1/2 or less and only using WOT in short burst then you will be fine
6S setup
motor
http://www.hobbyking.com/hobbyking/...SK3_4250_500kv_Brushless_Outrunner_Motor.html
ESC
This esc will work for the 4S or 6S setup. Its a little pricey buts its nice because you can crank the voltage up to the BEC. Most only put 5 volts out and its nice to get it up to 6V for the servos but can go up to 8.4volt if your servos can take it.
http://www.hobbyking.com/hobbyking/...Platinum_100A_V3_Brushless_ESC_w_10A_BEC.html
Battery
The 6S pack you have will work but its a bit large and all that weight hanging off one side will make it KE different in both directions. I would drop back to either a pair of 3S 3300's in series or save some weight and drop back to like a pair of 2800-3000 mah 3S packs.
Prop Start with like a 13x6 and work from their but prop it to pull around 60/65 amps.
4S setup
Motor
http://www.valuehobby.com/power-systems/brushless-motors/outrunner-airplane/gforce-g32-800kv.html
Use the same ESC as listed above.
Battery
Use a 4S 3700-4000mah pack.
Prop
Start with like a 14x7 but you will want to prop it to pull around 80/90 amps. I know the specs on the motor only say 12x6 on 4S and max load of 50amps. Those are CJ numbers. If you plan to stay WOT the whole time it will cook the motor and we will need to figure out something else but if your like me and most the time the throttle will be 1/2 or less and only using WOT in short burst then you will be fine
kwj48
70cc twin V2
Here's my suggestion although the motor is out of stock,,, Run with a 13x6 Xoar.
motor= http://www.hobbypartz.com/86mc301-3520-900kv.html
batts= http://www.valuehobby.com/power-systems/batteries/4s-lipo/elite-60c-3300mah-4s-t.html
esc= http://www3.towerhobbies.com/cgi-bin/wti0001p?&I=LXCYNG&P=7
motor= http://www.hobbypartz.com/86mc301-3520-900kv.html
batts= http://www.valuehobby.com/power-systems/batteries/4s-lipo/elite-60c-3300mah-4s-t.html
esc= http://www3.towerhobbies.com/cgi-bin/wti0001p?&I=LXCYNG&P=7
bigblueswope
100cc
Awesome fellas! Thanks for the suggestions.
BJ Swope
BJ Swope
bigblueswope
100cc
Just because @Pistolera is a good IMAC pilot and he parks his bird in a tree doesn't mean we all have to...
BJ Swope
BJ Swope
